API 676, External Gear Pump,EGP Series

Overview

Sectional View

Exploded View

Documents

Horizontal, External gear pump to API 676 3rd.



  • Flow rate (Max.):   200 m3/hr
  • Differential pressure (Max.): 8 bar a
  • Speed (Max.): 1450 rpm
  • MAWP: 8 bar g
  • Operating temperature: -15 ˚C to 120 ˚C
  • Design temperature: 80 ˚C

  • Application

    • Fuel Oils
    • Open Circuit Servo
    • Quenching
    • Cutting and Cooling Fluids
    • Oil/Water Emulsions
    • Viscous Vegetable and Animal Fats
    • Bitumen
    • Wax
    • Paint
    • Lacquers
    • Viscose

  • Features

    • Double rotors for low noise and non pulsating flow.
    • Accurate manufacture of rotors and housings for high efficiency.
    • Robust journal roller bearings for long life and durability.
    • Single & double mechanical seals as options for shaft seal
    • API682 seal support system available
    • materials variants available for special orders. Motorised bracket base and flange mounted or pumps are available as standard.
    • Special baseplate designs  available on request.

  • Catalogue

    EGP-Catalogue 2015

  • IOM

    EGP-Installation, Operation & maintenance Manual- 2015

  • Data-sheet Forms

    EGP-Compact Data-sheet
